大單橋箱體容積可達69立方以上，滿足快遞快運行業需求;
輕量化設計，底盤自重5.3噸以內，輕量化行業領導者;
搭載東風康明斯發動機，法士特變速箱，東風德納橋，黃金
動力鏈高效無憂
整車車型 (底盤型號) | DFV5183XXYGP6D 廂式 (DFV1183GDP6DJ1) | DFV5183XXYGP6D1 廂式 (DFV1183GP6DJ1) | DFV5183XXYGP6D1 廂式 (DFV1183GP6DJ1) | DFV5183XYKGP6D1 翼開啟 (DFV1183GP6DJ1) |
外形尺寸 (mm) (長*寬*高) | 9000x2500， 2550x3900， 3990 | 9000,10100,10300,8100， 8500,10050,10250x2500， 2550x3780,3850, 3900,3960,3990 | 9000,10100,10300,8100， 8500,10050,10250x2500， 2550x3780,3850, 3900,3960,3990 | 12000,10600.10300.10100. 9150,9300,10150,9000,10050 10250x2500,2550x3800， 3900,3950,3990 |
箱體尺寸 (mm) (長*寬*高) | 6600,6700,6800x2400, 2440x2400,2500,2200, 2580,2680,2700,2750, 2800,2850,2900 | 9000,10100,10300,8100， 8500,10050,10250x2500， 2550x3780,3850, 3900,3960,3990 | 5800,6200,6600,6700,6800, 7700x2400,2450x2400, 2500,2600,2680,2700,2750, 2800,2820,2850,2900 | 6800,7700,7800,8000. 8300,9400,9500,9600,9750, 9800x2400,2450x2400, 2500,2600,2670,2700, 2750,2800,2820 |
整備質量 (kg) | 10425,9925, 10490,9990 | 11155,11220, 10755,10820 | 11155,11220, 10755,10820 | 8805,8870， 9615,9680 |
額定質量 (kg) | 7380,7880 | 6650,7050 | 6650,7050 | 9000,8190 |
| 軸距 | 3800,3950,4200,4500, 4700,5100,5600,6000 | 4500,4700,5100,5600, 7150,5800,3950,4200 | 4500,4700,5100,5600, 7150,5800,3950,4200 | 4500,4700,5100,5600, 7150,5800,3950,4200 |
| 發動機 | D6.7NS6B320,B6.2NS6B260,D4.5NS6B240 | |||
